The Coherent EC2G v2 is a industrial Low Power
Cellular Gateway with Serial interface in a compact housing. The device integrates all necessary functionality to automatically create outgoing and accept incoming IP and Circuit Switched Data connections.
With very low power consumption the EC2G is particularly suitable for battery and renewable energy powered applications.
Once configured the EC2G requires no intervention from a host device and operates autonomously as an intelligent GSM Gateway for connected equipment. Additional features can be configured to support legacy equipment and smooth the migration from using CSD to IP connectivity.
The EC2G is intended for high reliability remote monitoring applications, operating 24/7/ It is designed for operation over the industrial temperature range.
General Features
- Dual-band 2G for UK and pan-EU deployment (900/1800 MHz)
- Auto GPRS connection and CSD call open without AT-Commands
- Power Supply Input voltage range: 5 to 24 V D.C.
- Operating Temperature Range: -40 to + 85 ″C
Interfaces
- Single DB25 connector for combined Serial interface and D.C. power supply input
- Separate D.C. power input socket
- Optional Seral to USB interface + Power supply available for PC interface / programming
Software and other features
- Low power consumption: Sleep Mode (On-line, idle with no communications) <3.0mA @ 12v supply
- Multi-coloured LED indicates signal strength, and operational status
- Highly configurable software interface for simplified & legacy system compatibility
- Remote Telnet access via IP connection or CSD call.
- Fully certified for UK and EU deployment.
provides a simple and fast to use solution for interfacing EC2G Gateways to a PC.
device for metering applications where a record of pulse count data needs to be kept from multiple meters. The device has 8 pulse-count input channels which can be connected to meters over more than 250 meters of cable.
